Kingkar DPF cleaning machine is an innovative solution to clean all DPFs of vehicles.

It uses water flushing and high-pressure air purging that work alternately, it also has wave surge technology, so it can reach nearly 100% cleaning effect.
Triple cleaning technology = 100% cleaning effect.
2. One machine completes the operation = Easy operation, safety, saving time and labour.
3. Can clean all kinds & size of DPF, DOC, SCR = All vehicles can be cleaned.
4. Equipped the 10μm filter device = deep cleaning and reusable, save water and more eco-friendly.
5. Got the CE, ISO, NOA certificates and RoHS certificate for the cleaner agent, totally safe cleaning

Kingkar has cleaned tens of thousands of DPFs of different brands, such as car brands: BMW, Mercedes-Benz, Porsche, Land Rover, Hyundai, Honda, Toyota, Mazda, Peugeot, Buick, etc.

Truck brands: VOLVO, MAN, Freightliner, DAF, ISUZU, TATA, SCANIA, Peterbilt and so on.



DPF Cleaning Machine 5.0

Kingkar DPF5.0 machine specially designed for cars, it can also clean vans and light trucks, because its size of cleaning chamber up to 1 meter. And the entire left side of Kingkar DPF machine is the washing chamber, big and closed, which can also ensure the clean environment of your shop cleaning.
The right side of Kingkar DPF machine is the operation, as well as some electric devices. The design of the left and right structures of the machine ensures safety during the cleaning process.
Kingkar DPF machine is using warm water with cleaner agent and high-pressure air purging, most important, wave surge technology. Three-in-one process can make sure the cleaning effect nearly 100%.
First, warm water and cleaner agent soften the carbon ash inside the DPF. Secondly, during wave surge cleaning, high-pressure air will be released instantly every 20 seconds, so that carbon ash particles will be pushed from the honeycomb holes layer by layer, a total of 180 times, which can achieve nearly 100% cleaning effect. And it only takes 60 minutes to clean a DPF and will not cause a secondary blockage. It’s impeccable operation and usefulness.
Model 5.0
Voltage(AC) 220V single phase, 50HZ/60HZ
380V three phase, 50HZ/60HZ
Rated Capacity(KW) ≤14.5
Gas Tank Capacity(L) 25
Working Gas Pressure(Mpa) ≤6
Liquid Temperature(°C) 55-70
Outline Dimensions-LWH(mm) 1680*830*1725
Tank Pressure 8KG
Net Weight(KG) 470
Rated Capacity 14.5 (KW) Electricity
Control System PLC Control with Touch Screen
Function Gasoline & Diesel DPF, DOC, SCR Cleaning, DPF Regeneration
Certification CE, SGS, ISO”
